Flashcards in Anatomy Deck (495):
1

Label numbers 1-5

Q image thumb

1. Frontal sinuses

2. Tentorium osseum cerebelli

3. External occipital protuberance

4. Atlantooccipital joints

5. Air in nasopharynx

2

Label numbers 6-10

Q image thumb

6. Tympanic bullae

7. Stylohyoid bones

8. Soft palate

9. Tyrohyoid bones

10. Basihyoid bones



3

Label numbers 11-16

Q image thumb

11. Ceratohyoid bones

12. Epihyoid bones

13. Endotracheal tube

14. Inferior alveolar canals of the mandible

15. Inferior first molar teeth

16. Superior fourth premolar teeth

4

Label 17-21

Q image thumb

17. Superior canine teeth

18. Inferior canine teeth

19. Inferior incisor teeth

20. Superior incisor teeth

21. Hard palate

5

Label 1-6

Q image thumb

1. Cartilaginous nasal septum

2. Superior incisor 2

3. Superior canine tooth

4. Superior premolar 1

5. Superior premolar 3

6. Ethmoidal conchae

6

Label 7-12

Q image thumb

7. Maxillary recess

8. Superior premolar 4

9. Nasal septum

10. Dorsal and ventral nasal conchae

11. Superior premolar 2

12. Palatine fissure

7

Label 1-4

Q image thumb

1. Medial frontal sinus

2. Lateral frontal sinus

3. Zygomatic process of the frontal bone

4. Coronoid process of mandible

8

What is labeled in number 5?

Q image thumb

5. Atlantooccipital joint

9

What is labeled in number 2?

Q image thumb

2. Petrous temporal bone

10

What is labeled in number 4

Q image thumb

4. Tympanic bulla

11

What is labeled in number 3?

Q image thumb

3. Angular process of mandible



12

What is labeled as number 1?

Q image thumb

1. Nasopharynx

13

What is labeled as number 7?

Q image thumb

7. Jugular foramen

14

What is labeled as number 9?

Q image thumb

9. Zygomatic arch

15

Identify number 6.

Q image thumb

Foramen lacerum

16

Identify number 8

Q image thumb

Coronoid process of the mandible

17

Which of the following is not the correct ID?

1. Superior incisor 1

2. Superior incisor 3

4. Superior canine tooth

6. Superior premolar 1

Q image thumb

2. Superior incisor 3



** This is superior incisor 2

18

Label number 5

Q image thumb

Periodontal ligament

19

Label 6-11.

Q image thumb

6. Superior premolar 1

7. Superior premolar 2

8. Superior premolar 3

9. Superior premolar 4

10. Superior molar 1

11. Superior molar 2

20

ID number 12

Q image thumb

Caudal root of premolar 4

21

Number 13 is the _____ root of premolar 4 and 14 is the ____ root of premolar 4

Q image thumb

13. Rostomedial

14. Rostolateral

22

ID number 15

Q image thumb

Cortical bone forming wall of alveolous

23

Which of the following is ID incorrectly?

1. Inferior incisor 1

2. Inferior incisor 2

5. Inferior premolar 1

8. Inferior premolar 3

Q image thumb

8. Inferior premolar 3



***This is inferior premolar 4

24

Which of the following is labeled incorrectly?

3. Inferior incisor 2

4. Inferior canine tooth

5. Inferior premolar 1

6. Inferior premolar 2

Q image thumb

3. Inferior incisor 2



** Its inferior incisor 3

25

What is number 9?

Q image thumb

Dental vacity of inferior molar 1

26

Identify number 10 and 11

Q image thumb

10. Inferior molar 2

11. Inferior molar 3

27

ID numbers 12 and 13

Q image thumb

12. Mandibular foramen

13. Mandibular canal

28

What is number 14?

Q image thumb

Cortical bone forming wall of alveolous

29

What is number 15?

Q image thumb

Periodontal ligament

30

Nuber 7 is the ____ of C4 and number 8 is the ____ of C4.

Q image thumb

7. Spinous process of C4

8. Vertebral canal of C4

31

ID number 1.

Q image thumb

Lateral vertebral foramina (left and right) of atlas; emergence of cervical nerve 1

32

ID number 2 and 3

Q image thumb

2. Dorsal arch of atlas (C1)

3. Spinous process of axis (C2)

33

ID number 4.

Q image thumb

4. Synovial joints between articular process of C2 and C3

34

Which of the following are not matched correctly?

5. Spinous process of C3

9. Spinous process of C4

10. Spinous process of C5

11. Spinous process of C6

Q image thumb

9. Spinous process of C4

10. Spinous process of C5

11. Spinous process of C6



** 9. C5

10. C6

11. C7

35

ID number 6.

Q image thumb

Caudal articular processes of C3

36

ID the structure labeled 12

Q image thumb

Trachea

37

Match the following with numbers 14-19

Body of C4

Transverse processes of C4

Caudal extremity (fossa) of C4

Cranial articular processes of C4

Caudal physis of C5

Cranial exremity (head) of C6



Q image thumb

14. Cranial exremity (head) of C6

15. Caudal physis of C5



16. Caudal extremity (fossa) of C4

17. Body of C4

18. Transverse processes of C4

19. Cranial articular processes of C4

38

ID number 13

Q image thumb

Expanded ventral laminae of transverse processes of C6

39

Match the following with numbers 20-24:

Wings (transverse processes) of atlas

Intervertebral foramina between C2 and C3

Ventral tubercle of atlas

Endotracheal tube

Intervertebral space (disk) between C2 and C3

Q image thumb

20. Intervertebral foramina between C2 and C3

21. Intervertebral space (disk) between C2 and C3

22. Endotracheal tube

23. Wings (transverse processes) of atlas

24. Ventral tubercle of atlas

40

True/False. Number 3 is the atlantooccipital joint and number 22 is the atlantoaxial joint

Q image thumb

False.

**3. Atlatoaxial joint

22. Right atlantooccipital joint

41

ID the structure labeled as number 5.

Q image thumb

5. Left thyroihyoid bone

42

Match the following with numbers 15-19

Spinous process of C6

Spinous process of C5

Spinous process of C4

Spinous process of C7

Spinous process of T1

Q image thumb

15. Spinous process of T1

16. Spinous process of C7

17. Spinous process of C6

18. Spinous process of C5

19. Spinous process of C4

43

What is labaled as number 1?

Q image thumb

Left occipital condyle

44

Which of the following is labeled as number 8?

a. Left transverse process of C3

b. Left transverse process of C4

c. Left transverse process of C5

d. Left transverse process of C6

Q image thumb

a. Left transverse process of C3

45

ID the structure labeled as number 2

Q image thumb

Dens of the axis

46

Which of the following is the correct ID for number 4?

a. Spinous process of the atlas

b. Spinous process of the axis

c. Transverse process of the atlas

d. Transverse process of the axis

Q image thumb

b. Spinous process of the axis

47

Match the following with numbers 6-10:

Tracheal cartilages

Left transverse process of C3

Left transverse process of axis

Left caudal articular process of C3

Left cranial articular process of C4

Q image thumb

6. Left transverse process of axis

7. Tracheal cartilages

8. Left transverse process of C3

9. Left caudal articular process of C3

10. Left cranial articular process of C4

48

ID numbers 11-14

Q image thumb

11. Left transverse process of C4

12. Left transverse process of C5

13. Left transverse process of C6

14. Left transverse process of C7

49

Match the following with numbers 20-22:

Right atlantooccipital joint

Right wing of atlas

Inververtebral space (disk) between C3 and C4

Q image thumb

20. Inververtebral space (disk) between C3 and C4

21. Right wing of atlas

22. Right atlantooccipital joint

50

Match the following with numbers 1-7:

Caudal articular process of T7

Cranial articular process of T8

Spinous process of T10

Body of T6

First pair of ribs

Intervertebral space (disk) between T7 and T8

Spinous process of T11 (anticlinical vertebra)

Q image thumb

1. Spinous process of T10

2. Spinous process of T11 (anticlinical vertebra)

3. Cranial articular process of T8

4. Intervertebral space (disk) between T7 and T8

5. Body of T6

6. First pair of ribs

7. Caudal articular process of T7

51

ID number 8.

Q image thumb

Mamillary processes atop cranial articular processes of T12

52

Number 9 is the ____ process of T12 and number 10 is the ____ processes of T12.

Q image thumb

9. Spinous process of T12

10. Accessory processes of T12

53

Which number correlates to the caudal articular process of L1?

Q image thumb

Number 11

54

ID number 13 -15 with regards to the lumbar vertebrae

Q image thumb

13. Spinous process of L2

14. Vertebral canal of L2

15. Intervertebral foramina between L2 and L3

55

Match the following with numbers 16-19:

Twelfth pair of ribs

Transverse process of L4

Thirteenth pair of ribs

Intervertebral space (disk) between T11 and T12

Q image thumb

16. Transverse process of L4

17. Thirteenth pair of ribs

18. Twelfth pair of ribs

19. Intervertebral space (disk) between T11 and T12

56

ID number 12

Q image thumb

Cranial articular processes of L1

57

Which of the following is matched incorrectly?

20. Mamillary process atop cranial articular processes of T12

21. Accessory process of T13

22. Intervertebral foramina between L1 and L2

23. Cranial articular process of L3

Q image thumb

23. Cranial articular process of L3



** Caudal articular process of L3

58

What is number 26?

Q image thumb

Promontory of sacrum

59

ID number 24.

Q image thumb

Cranial articular processes of L3

60

ID number 25

Q image thumb

Secondary ossification center for crest of ilium

61

Correctly match the following with numbers 27-30:

Transverse processes of L6

Heads of thirteeth ribs superimposed on body of T13

Heads of twelfth ribs superimposed on body of T12

Intervertebral space (disk) between L7 and S1

Q image thumb

27. Intervertebral space (disk) between L7 and S1

28. Transverse processes of L6

29. Heads of thirteeth ribs superimposed on body of T13

30. Heads of twelfth ribs superimposed on body of T12

62

ID numbers 1 and 2.

Q image thumb

1. Intervertebral space (disk) between T13 and L1

2. Left accessory process of L2

63

ID number 7

Q image thumb

Left sacroiliac joint

64

Which of the following are incorrectly matched?

3. Spinous process of L3

4. Left transverse process of L4

5. Left caudal articular process of L5

6. Left cranial articular process of L6

Q image thumb

5. Left caudal articular process of L5

6. Left cranial articular process of L6



***5. Left cranial articular process of L5

6. Left caudal articular process of L6

65

ID number 8

Q image thumb

Metallic foreign bodies in descending colon

66

What number repersents the spinous process of T1?

Q image thumb

Number 13

67

Correctly match the following with numbers 9-12:

Sternum superimposed over vertebrae

Tubercle of right rib 3

Costal cartilage of right rib 11

Head of right rib 3, articulating with bodies of vertebrae T2 and T3

Q image thumb

9. Costal cartilage of right rib 11

10. Sternum superimposed over vertebrae

11. Tubercle of right rib 3

12. Head of right rib 3, articulating with bodies of vertebrae T2 and T3

68

Is this the lateral or medial view of the equine guttural pouches and laryngeal area?

Q image thumb

Lateral

69

What number is the occipital condyles?

Q image thumb

Number 4

70

ID number 2

Q image thumb

Hypoglossal canals

71

What number is the dens of axis?

Q image thumb

Number 5

72

ID number 15

Q image thumb

Stylohyoid bones

73

Which number represents the longus capitis muscles?

Q image thumb

Number 13

74

ID number 1

Q image thumb

Petrous temporal bones

75

Which number shows early mineralization within thyroid cartilages of the larynx?

Q image thumb

Number 8

76

Which number represents the lateral vertebral foramina of the atlas?

Q image thumb

Number 3

77

ID number 1

Q image thumb

Spine of the scapula

78

Which number is the infraglenoid tubercle of the scapula?

Q image thumb

Number 3

79

ID nuimber 4

Q image thumb

Head of the humerus

80

ID number 7

Q image thumb

Greater tubercle of the humerus

81

Which number represents the proximal physis of the humerus?

Q image thumb

Number 6

82

ID number 2

Q image thumb

Acromion of the scapula

83

Which number is the glenoid cavity of the scapula?

Q image thumb

Number 5

84

ID number 8

Q image thumb

Supraglenoid tubercle of the scapula

85

ID numbers 1 and 2

Q image thumb

1. Spine of the scapula

2. Acromion of the scapula

86

The Clavicle is seen in which number?

Q image thumb

Number 6

87

Which numbers represent the lesser tubercle and the greater tubercle of the humerus?

Q image thumb

3. Greater tubercle of the humerus

5. Lesser tubercle of the humerus

88

ID number 4

Q image thumb

Humeral (scapulohumeral) joint

89

Name the view of this radiograph of the canine humerus

Q image thumb

Mediolateral

90

Which number represents the tuber olecrani?

Q image thumb

Number 5

91

Which number represents the lateral epicondyle of the humerus?

Q image thumb

Number 4

92

ID number 1

Q image thumb

Infraglenoid tubercle of the scapula

93

ID number 13

Q image thumb

Greater tubercle of the humerus

94

Which number represnts the head of the radius?

Q image thumb

Number 10

95

ID number 7

Q image thumb

Lateral coronoid process of the ulna

96

Number 12 is the proximal _____ of the humerus

Q image thumb

12. Proximal physis of the humerus

97

ID number 2

Q image thumb

Head of the humerus

98

ID number 6

Q image thumb

Medial epicondyle of the humerus

99

Which number represents the anconeal process of the ulna?

Q image thumb

Number 3

100

ID number 14

Q image thumb

Supraglenoid tubercle of the scapula

101

What number represents the condyle of the humerus?

Q image thumb

Number 11

102

ID number 9

Q image thumb

Medial coronoid process of the ulna

103

ID number 8

Q image thumb

Proximal radioulnar joint

104

State the view of the canine humerus radiograph

Q image thumb

Caudocranial

105

ID number 3

Q image thumb

Deltoid tuberosity

106

Which number is the acromion of the scapula?

Q image thumb

Number 1

107

ID number 10

Q image thumb

Clavicle

108

Which is the lateral epicondyle of the humerus and which is the medial epicondyle of the humerus?

Q image thumb

5. Lateral epicondyle of the humerus

9. Medial epicondyle of the humerus

109

True/False. The Greater tubercle of the humerus is seen in number 4

Q image thumb

False. Its seen in number 2

110

ID number 6

Q image thumb

Capitulum of the humeral condyle

111

ID number 11

Q image thumb

Lesser tubercle of the humerus

112

Is number 7 the medial or lateral coronoid process of the ulna?

Q image thumb

Medial coronoid process of the ulna

113

Which number is the trochlea of the humeral condyle?

Q image thumb

Number 8

114

ID number 4

Q image thumb

Supratrochlear foramen of the humerus

115

Name the view of this radiograph

Q image thumb

Mediolateral

116

ID 1 and 2 with respect to the ulna

Q image thumb

1. Anconeal process of the ulna

2. Tuber olecrani of the ulna

117

Which number represents the head of the radius?

Q image thumb

Number 8

118

ID numbers 10 and 11 in regards to the cranial border of the epicondyle of the humerus

Q image thumb

10. Cranial border of medial epicondyle of humerus

11. Cranial border of lateral epicondyle of humerus

119

ID number 6

Q image thumb

Proximal radioulnar joint

120

Number ___ is the medial coronoid process of the ulna and number ____ is the lateral coronoid process of the ulna.

Q image thumb

5. Lateral coronoid process of the ulna

7. Medial coronoid process of the ulna

121

ID number 9

Q image thumb

Condyle of the humerus

122

ID numbers 3 and 4

Q image thumb

3. Caudal border of lateral epicondyle of the humerus

4. Caudal border of medial epicondyle of the humerus

123

Which number represents the medial part and the lateral part of the humeral condyle?

Q image thumb

3. Medial part of humeral condyle

4. Lateral part of humeral condyle

124

ID number 1

Q image thumb

Medial epicondyle of the humerus

125

ID number 2

Q image thumb

Anconeal process of ulna

126

ID number 5

Q image thumb

Caudal border of lateral epicondyle of the humerus

127

ID the head of the radius

Q image thumb

Number 5

128

Which number is the anconeal process of the ulna?

Q image thumb

Number 8

129

ID number 1

Q image thumb

Tuber olecrani of the ulna

130

Which number is the lateral epicondyle of the humerus and which number is the medial epicondyle of the humerus?

Q image thumb

2. Medial epicondyle of the humerus

7. Lateral epicondyle of the humerus

131

ID number 4

Q image thumb

Medial coronoid process of the ulna

132

ID number 6

Q image thumb

Capitulum of the humeral condyle

133

Which number represents the supratrochlear foramen of the humerus?

Q image thumb

Number 9

134

ID number 3

Q image thumb

Trochlea of the humeral condyle

135

Which number represents the medial epicondyle of the humerus?

Q image thumb

Number 3

136

ID number 1

Q image thumb

Supratrochlear foramen of the humerus

137

ID number 12

Q image thumb

Anconeal process of the ulna

138

Which number represents the supratrochlear foramen of the humerus?

Q image thumb

Number 13

139

Which number represents the tuber olecrani of the ulna?

Q image thumb

Number 6

140

ID number 2

Q image thumb

Anconeal process of the ulna

141

ID number 7

Q image thumb

Tuber olecrani of the ulna

142

Which number represents the medial coronoid process of the ulna?

Q image thumb

Number 5

143

ID number 11

Q image thumb

Lateral epicondyle of the humerus

144

Which number represents the trochlear notch of the ulna?

Q image thumb

Number 4

145

Which number represents the head of the radius?

Q image thumb

Number 9

146

Which number is the sesamoid bone of the supinator muscle (inconsistent)?

Q image thumb

Number 10

147

ID number 8

Q image thumb

Medial epicondyle of the humerus

148

Name the view shown in this radiographic image of the canine antebrachium.

Q image thumb

Mediolateral

149

Match the following with numbers 14-16:

Body of radius

Head of radius

Neck of radius

Q image thumb

14. Body of radius

15. Neck of radius

16. Head of raidus

150

ID numbers 11-13

Q image thumb

11. Distal epiphysis of radius

12. Distal physis of radius

13. Distal metaphysis of radius

151

Which number represents the accessory carpal bone?

Q image thumb

Number 8

152

ID number 10

Q image thumb

Antebrachiocarpal joint

153

ID number 4

Q image thumb

Proximal radioulnar joint

154

ID number 9

Q image thumb

Carpal pad

155

Match the following with numbers 1-3

Lateral epicondyle of the humerus

Medial epicondyle of the humerus

Tuber olecrani of the ulna

Q image thumb

1. Tuber olecrani of the ulna

2. Lateral epicondyle of the humerus

3. Medial epicondyle of the humerus

156

Number 6 is the distal _____ of the ulna and number 7 is the distal ____ of the ulna.

Q image thumb

6. Distal metaphysis of the ulna

7. Distal epiphysis of the ulna

157

ID number 17

Q image thumb

Elbow (cubital) joint

158

What is number 5?

Q image thumb

Body of the ulna

159

ID number 18

Q image thumb

Condyle of the humerus

160

Which of the following correctly matches the radiographic view of the canine antebrachium?

a. Caudocranial

b. Craniocaudal

c. Dorsoventral

d. Ventrodorsal

Q image thumb

b. Craniocaudal

161

Which number represents the ulnar carpal bone?

Q image thumb

Number 8

162

Which number represents the lateral epicondyle of the humerus?

Q image thumb

Number 14

163

ID numbers 1 and 2

Q image thumb

1. Medial epicondyle of the humerus

2. Medial coronoid process of the ulna

164

Number ____ represents the body of the ulna and number ____ represents the body of the radius

Q image thumb

11. Body of ulna

3. Body of radius

165

ID number 6

Q image thumb

Intermedioradial carpal bone

166

Number 4 is the distal ___ of the radius and number 5 is the distal ___ of the radius.

Q image thumb

4. Distal metaphysis of the radius

5. Distal epiphysis of the radius

167

Which number is the elbow (cubital) joint?

Q image thumb

Number 13

168

Which number represents the body of the ulna?

Q image thumb

Number 11

169

ID number 7

Q image thumb

Sesamoid bone of the abductor pollicis longus

170

Which number represents the distal metaphysis of the ulna?

Q image thumb

Number 10

171

ID number 9

Q image thumb

Distal epiphysis (styloid process) of the ulna

172

ID the second carpal bone

Q image thumb

Number 10

173

ID number 12

Q image thumb

Carpometacarpal joint

174

Which number represents the middle carpal joint?

Q image thumb

Number 6

175

Match the following with numbers 1-5:

Distal epiphysis of the radius

Distal metaphysis of the radius

Distal physis of the radius

Antebrachiocarpal joint

Styloid process (medial) of the raidus

Q image thumb

1. Distal physis of the radius

2. Distal metaphysis of the radius

3. Antebrachiocarpal joint

4. Distal epiphysis of the radius

5. Styloid process (medial) of the radius

176

Match the following with numbers 11-15:

First metacarpal bone

Fifth metacarpal bone

Fourth carpal bone

Third carpal bone

Carpometacarpal joint

Q image thumb

11. First metacarpal bone

12. Carpometacarpal joint

13. Third carpal bone

14. Fifth metacarpal bone

15. Fourth carpal bone

177

What number represents the ulnar carpal bone?

Q image thumb

Number 17

178

Which is the first carpal bone?

Q image thumb

Number 9

179

Which number is the sesamoid bone of the abductor pollicis longus?

Q image thumb

Number 8

180

ID number 19

Q image thumb

Distal radioulnar joint

181

ID number 20

Q image thumb

Distal metaphysis of the ulna

182

ID number 18

Q image thumb

Distal epiphysis (styloid process) of the ulna

183

ID number 4

Q image thumb

Carpal pad

184

ID number 9

Q image thumb

Antebrachiocarpal joint

185

Which number represents the accessory carpal bone?

Q image thumb

Number 2

186

ID number 5

Q image thumb

Proximal sesamoid bone of the first digit

187

ID number 1

Q image thumb

Distal epiphysis (styloid process) of the ulna

188

ID number 3

Q image thumb

Ulnar carpal bone

189

ID numbers 7 and 8

Q image thumb

7. Carpometacarpal joint

8. Middle carpal joint

190

ID number 10

Q image thumb

Distal epiphysis of the radius

191

Match the following with numbers 1-4:

Distal radioulmnar joint

Base of metacarpal bone 5

Ulnar carpal bone

Accessory carpal bone

Q image thumb

1. Distal radioulnar joint

2. Accessory carpal bone

3. Ulnar carpal bone

4. Base of metacarpal bone 5

192

ID numbers 5-7

Q image thumb

5. First carpal bone

6. Second carpal bone

7. Middle carpal joint

193

ID number 8

Q image thumb

Intermedioradial carpal bone

194

What is number 9?

Q image thumb

Antebrachiocarpal joint

195

Which number represents the proximal phalynx of digit 2?

Q image thumb

Number 10

196

ID number 15

Q image thumb

Metacarpal pad

197

ID number 11

Q image thumb

Middle phalanx of digit 2

198

Match the following with numbers 4-8:

Metacarpal bone 1

First carpal bone

Distal phalanx of digit 1

Proximal phalanx of digit 1

Second metacarpal bone

Q image thumb

4. First carpal bone

5. Metacarpal bone 1

6. Proximal phalanx of digit 1

7. Distal phalanx of digit 1

8. Second metacarpal bone

199

ID number 2

Q image thumb

Intermedioradial carpal bone

200

Which number is the sesamoid bone of the abductor pollicis longus?

Q image thumb

Number 3

201

ID number 1

Q image thumb

1. Distal epiphysis of the radius

202

ID number 9

Q image thumb

Abaxial proximal sesamoid bone of digit 2

203

ID numbers 12 and 13

Q image thumb

12. Unguicular crest of distal phalanx of digit 2

13. Unguicular process of distal phalanx of digit 2

204

ID number 14

Q image thumb

Digital pad of digit 3

205

ID numbers 16-18 with relation to the joints of digit 5

Q image thumb

16. Distal interphalangeal joint of digit 5

17. Proximal interphalangeal joint of digit 5

18. Metacarpophalangeal joint of digit 5

206

ID the ulnar carpal bone

Q image thumb

Number 22

207

Number ___ is the fourth metacarpal bone and number ___ is the third metacarpal bone.

Q image thumb

19. Fourth metacarpal bone

20. Third metacarpal bone

208

What is number 21?

Q image thumb

Carpal pad

209

ID number 23

Q image thumb

Accessory carpal bone

210

ID number 24

Q image thumb

Distal epiphysis (styloid process) of the ulna

211

ID number 8

Q image thumb

Antebrachiocarpal joint

212

ID number 3

Q image thumb

Ulnar carpal bone

213

ID number 9

Q image thumb

Distal epiphysis of the radius

214

Which number represents the distal phalanx of digit 1?

Q image thumb

Number 6

215

ID number 7

Q image thumb

Dorsal sesamoid bone

216

Which number is the carpal pad?

Q image thumb

Number 4

217

ID number 5

Q image thumb

Proximal sesamoid bone in digit 1

218

ID numbers 1 and 2

Q image thumb

1. Distal epiphysis (styloid process) of the ulna

2. Accessory carpal bone

219

ID numbers 8-11 in regards to the digits

Q image thumb

8. Digital pad of digit 4

9. Flexor tubercle of distal phalanx of digit 4

10. Unguicular crest of distal phalanx of digit 4

11. Unguicular process of distal phalanx of digit 3

220

Which number represents the dorsal sesamoid bone of digit 2?

Q image thumb

Number 13

221

ID the accessory carpal bone

Q image thumb

Number 2

222

ID the middle carpal joint

Q image thumb

Number 14

223

What is number 6?

Q image thumb

Middle phalanx of digit 5

224

ID number 3.

Q image thumb

Ulnar carpal bone

225

ID number 7

Q image thumb

Metacarpal pad

226

True/False. Number 12 is the proximal phalanx of digit 3

Q image thumb

False its of digit 2

227

ID number 2

Q image thumb

Accessory carpal bone

228

Which is the body of metcarpal bone 5?

Q image thumb

Number 4

229

Which number is the abaxial proximal sesamoid bone of digit 5?

Q image thumb

Number 5

230

What number represents the distal epiphysis (styloid process) of the ulna?

Q image thumb

Number 1

231

Match the following with numbers 1-5:

Body of the left ilium

Body of the left pubis

Head of the left femur

Wing of the left ilium

Crest of the left ilium

Q image thumb

1. Crest of the left ilium

2. Wing of the left ilium

3. Body of the left ilium

4. Body of the left pubis

5. Head of the left femur

232

Which number is the body of the right femur?

Q image thumb

Number 11

233

ID number 15

Q image thumb

Acetabular fossa

234

ID number 13

Q image thumb

Right obturator foramen

235

ID number 19

Q image thumb

Right sacroiliac joint

236

Which number represents the fovea capitis of the right femur?

Q image thumb

Number 16

237

ID number 6

Q image thumb

Greater trochanter of the left femur

238

ID number 8

Q image thumb

Caudal vertebra 4

239

ID the body of the left ischium

Q image thumb

Number 7

240

What number is the caudodorsal aspect of lunate surface of the acetabulum?

Q image thumb

Number 14

241

ID number 10

Q image thumb

Ischial arch

242

Which number represents the cranioventral aspect of lunate surface fo the acetabulum?

Q image thumb

Number 17

243

ID number 18

Q image thumb

Sacral vertebra 3

244

ID the right tuber ischiadicum (ischiatic tuberosity)

Q image thumb

Number 12

245

ID number 20

Q image thumb

Right tuber coxae (cranioventral iliac spine)

246

Which is the table of the left ischium?

Q image thumb

Number 9

247

Which of the following is the view of this canine pelvis?

a. Right-Left Medial

b.Left-Right Medial

c. Right-Left Lateral

d. Left- Right Lateral

Q image thumb

c. Right-Left Lateral

248

Match the following with numbers 10-14:

Head of the right femur (more magnified)

Body of the right femur (more magnified)

Body of the left femur (less magnified)

Body of the left ilium (less magnified)

Body of the right ilium (more magnified)

Q image thumb

10. Body of the right femur (more magnified)

11. Body of the left femur (less magnified)

12. Head of the right femur (more magnified)

13. Body of the left ilium (less maginified)

14. Body of the right ilium (more magnified)

249

ID number 7

Q image thumb

Left coxal joint

250

Which number is the caudaodorsal iliac spine?

Q image thumb

Number 3

251

ID number 6

Q image thumb

Caudal vertebra 2

252

ID number 15

Q image thumb

Promontory of sacrum

253

ID number 5

Q image thumb

Sacral vertebra 3

254

Which number is the superimporsed right and left tubera ischiadica?

Q image thumb

Number 8

255

ID number 1

Q image thumb

Crest of the right ilium

256

ID number 2

Q image thumb

Craniodorsal iliac spine

257

ID number 4

Q image thumb

Left tuber sacrale

258

Which number is the superimporsed right and left obturator foramina?

Q image thumb

Number 9

259

ID the patella

Q image thumb

Number 6

260

Match the following with numbers 16-19:

Neck of the femur

Head of the femur

Trochanteric fossa of the femur

Greater trochanter of the femur

Q image thumb

16. Trochanteric fossa of the femur

17. Greater trochanter of the femur

18. Neck of the femur

19. Head of the femur

261

ID number 2

Q image thumb

Fovea capitis of the femur

262

Which number is the cranioventral and which number is the caudodorsal aspect of lunate surface of the acetabulum?

Q image thumb

1. Cranioventral aspect of lunate surface of the acetabulum

4. Caudodorsal aspect of lunate surface of the acetabulum

263

ID the acetabular fossa

Q image thumb

Number 3

264

ID number 5

Q image thumb

Lesser trochanter of the femur

265

Match the following with numbers 7-10:

Medial sesamoid of gastrocnemius muscle

Medial condyle of the femur

Medial condyle of the tibia

Medial epicondyle of the femur

Q image thumb

7. Medial seamoid of gastrocnemius muscle

8. Medial epicondyle of the femur

9. Medial condyle of the femur

10. Medial condyle of the tibia

266

ID number 15

Q image thumb

Tuber ischiadicum

267

Which number is the body of the femur?

Q image thumb

Number 14

268

Which is the lateral sesamoid of the gastrocnemius muscle?

Q image thumb

Number 13

269

ID number 11

Q image thumb

Extensor fossa of the femur

270

ID number 12

Q image thumb

Lateral epicondyle of the femur

271

Match the following with numbers 10-13:

Body of the femur

Head of the femur

Neck of the femur

Patella

Q image thumb

10. Patella

11. Body of the femur

12. Neck of the femur

13. Head of the femur

272

ID the fibula

Q image thumb

Number 8

273

Which number is the craniodorsal aspect of lunate surface of the acetabulum?

Q image thumb

Number 14

274

ID number 9

Q image thumb

Tibial tuberosity

275

Which is the nutrient canal of the femur?

Q image thumb

Number 3

276

Which number is the lateral sesamoid and which number is the medial sesamoid of the gastrocnemius muscle?

Q image thumb

4. Lateral sesamiod of the gastrocnemius muscle

5. Medial sesamoid of the gastrocnemius muscle

277

ID numbers 1 and 2

Q image thumb

1. Trochanteric fossa of the femur

2. Lesser trochanter of the femur

278

Which number is the medial and lateral condyle of the femur?

Q image thumb

Number 6

279

What number is the sesamoid bone of the popliteus muscle?

Q image thumb

Number 7

280

ID number 6

Q image thumb

Intercondylar fossa of the femur

281

Which number is the lateral sesamoid of the gastrocnemius muscle?

Q image thumb

Number 16

282

Match the following with numbers 4-7:

Medial epicondyle of the femur

Medial condyle of the femur

Medial condyle fo the tibia

Intercondylar fossa of the femur

Q image thumb

4. Medial epicondyle of the femur

5. Medial condyle of the femur

6. Intercondylar fossa of the femur

7. Medial condyle of the tibia

283

ID numbers 1 and 2

Q image thumb

1. Base of the patella

2. Apex of the patella

284

What number represents the medial sesamiod of the gastrocnemius muscle?

Q image thumb

Number 3

285

ID the lesser condyle of the tibia

Q image thumb

Number 14

286

ID the cranial border of the tibia

Q image thumb

Number 10

287

Which is the medial tubercle and which is the lateral tubercle of the intercondylar eminence?

Q image thumb

8. Medial tubercle of the intercondylar eminence

9. Lateral tubercle of the intercondylar eminence

288

Number ___ is the body of the fibula and number ____ is the head of the fibula.

Q image thumb

11. Body of the fibula

13. Head of the fibula

289

ID number 12

Q image thumb

Sesamoid bone of the popliteus muscle

290

Which number is the extensor fossa of the femur?

Q image thumb

Number 15

291

ID number 14

Q image thumb

Lateral condyle of the tibia

292

Which number is the lateral sesamoid and which number is the medial sesamiod of the gastrocnemius muscle?

Q image thumb

1. Lateral sesamoid of the gastrocnemius muscle

2. Meidal sesamoid of the gastrocnemius muscle

293

Number ___ is the head of the fibula and number ___ is the body of the fibula

Q image thumb

6. Head of the fibula

7. Body of the fibula

294

ID number 4

Q image thumb

Extensor fossa of the femur

295

Which number is the medial and lateral condyles of the femur?

Q image thumb

Number 3

296

Which is the sesamoid bone of the popliteus muscle?

Q image thumb

Number 5

297

Which is the cranial border of the tibia?

Q image thumb

Number 8

298

ID number 10

Q image thumb

Tibial tuberosity

299

ID number 9

Q image thumb

Cartilage between the tibial tuberosity and the body of the tibia

300

Which is the patellar ligament?

Q image thumb

Number 13

301

Which are superimposed ridges of the femoral trochlea?

Q image thumb

Number 14

302

Which is the cranial border of the tibia?

Q image thumb

Number 8

303

What is number 12?

Q image thumb

Infrapatellar fat body

304

Which is the cranial intercondylar area of the tibia?

Q image thumb

Number 11

305

ID number 7

Q image thumb

Tuber calcanei

306

Match the following with numbers 1-5:

Body of the tibia

Medial border of the tibia

Medial condyle of hte tibia

Medial condyle of the femur

Medial meniscus

Q image thumb

1. Medial condyle of the femur

2. Medial meniscus

3. Medial condyle of the tibia

4. Medial border of the tibia

5. Body of the tibia

307

ID the lateral condyle of the tibia

Q image thumb

Number 20

308

ID number 14

Q image thumb

Interosseous membrane

309

Match the following with numbers 8-13:

Lateral malleolous of the fibula

Medial malleolous of the tibia

Medial aspect of the tarsocrural joint

Medial groove of the tibial cochlea

Lateral surface of the fibula

Lateral border of the tibia

Q image thumb

8. Medial groove of the tibial cochlea

9. Medial malleolous of the tibia

10. Medial aspect of the tarsocrural joint

11. Lateral malleolous of the fibula

12. Lateral surface of the fibula

13. Lateral border of the tibia

310

ID the medial surface of the fibula

Q image thumb

Number 6

311

Number ___ is the head of the fibula and number ___ is the body of the fibula

Q image thumb

15. Body of the fibula

19. Head of the fibula

312

ID the cranial border of the tibia

Q image thumb

Number 16

313

Which number is the medial tubercle and which number is the lateral tubercle of the intercondylar eminence?

Q image thumb

17. Medial tubercle of the intercondylar eminence

18. Lateral tubercle of the intercondylar eminence

314

ID the lateral condyle of the tibia

Q image thumb

Number 20

315

ID number 21

Q image thumb

Lateral meniscus

316

Which is the central intercondylar area of the tibia?

Q image thumb

Number 22

317

ID number 9

Q image thumb

Tuber calcanei

318

ID number 15

Q image thumb

Tibial tuberosity

319

 ID the medial and lateral sesamoid of the gastrocnemius muscle

Q image thumb

1. Lateral sesamoid of the gastrocnemius muscle

2. Medial sesamoid of the gastrocnemius muscle

320

ID number 8

Q image thumb

Tarsocrural jiont

321

ID the medial and lateral condyle of the femur

Q image thumb

3. Medial condyle of the femur

4. Lateral condyle of the femur

322

Which is the head of the fibula and which is the body?

Q image thumb

6. Head of the fibula

7. Body of the fibula

323

ID number 5

Q image thumb

Sesamoid bone of the popliteus muscle

324

ID number 10

Q image thumb

Proximal intertarsal joint

325

Which is the cartilage between the tibial tuberosity and body of the tibia?

Q image thumb

Number 14

326

Which is the body of the fibula superimposed on the tibia?

Q image thumb

Number 12

327

ID number 11

Q image thumb

Trochlea of the talus

328

Which is the cranial border of the tibia?

Q image thumb

Number 13

329

ID number 16

Q image thumb

Extensor fossa of the femur

330

ID numbers 1-4

Q image thumb

1. Tuber calcanei

2. Body of the calcaneous

3. Fourth tarsal bone

4. Metatarsal bone 1

331

ID number 6

Q image thumb

Tarsometatarsal joints

332

ID the distal intertarsal joint

Q image thumb

Number 8

333

ID number 11

Q image thumb

Trochlea tali

334

Which number is superimposed metatarsal bone 2 through metatarsal bone 5?

Q image thumb

Number 5

335

ID number 7

Q image thumb

Third tarsal bone

336

ID number 9

Q image thumb

Central tarsal bone

337

Which is the proximal intertarsal joint?

Q image thumb

Number 10

338

ID number 12

Q image thumb

Tarsocrural joint

339

ID numbers 8-12 relating to the metatarsal bones

Q image thumb

8. Base of metatarsal bone 5

9. Metatarsal bone 4

10. Metatarsal bone 3

11. Metatarsal bone 2

12. Metatarsal bone 1

340

ID number 15

Q image thumb

Central tarsal bone

341

ID number 18

Q image thumb

Sustentaculum tali of the calcaneus

342

Which number represents superimposed first tarsal bone and second tarsal bone?

Q image thumb

Number 14

343

Which number is the fourth tarsal bone?

Q image thumb

Number 6

344

ID numbers 1-5

Q image thumb

1. Body of the fibula

2. Tuber calcanei

3. Lateral malleolus of the fibula

4. Body of the calcaneus

5. Proximal intertarsal (calcaneoquartal) joint

345

ID number 7

Q image thumb

Tarsometatarsal joints

346

ID number 13

Q image thumb

Third tarsal bone

347

ID the medial malleolus of the tibia

Q image thumb

Number 19

348

ID number 20

Q image thumb

Tarsocrural joint

349

Which is the common calcanean tendon superimposed on the tibia?

Q image thumb

Number 21

350

ID number 17

Q image thumb

Talus

351

ID numbers 5-8

Q image thumb

5. Base of metatarsal bone 5

6. Metatarsal bone 4

7. Metatarsal bone 3

8. Metatarsal bone 2

352

Which is the tuber calcanei?

Q image thumb

Number 1

353

Which is the proximal intertarsal (calcenoquartal) joint and which is the proximal intertarsal (talocalcaneocentral) joint?

Q image thumb

2. Proximal intertarsal (calcaneoquartal) joint

11. Proximal intertarsal (talocalcaneocentral) joint

354

ID number 3

Q image thumb

Fourth tarsal bone

355

ID number 10

Q image thumb

Central tarsal bone

356

ID the sustentaculum tali of the calcaneus

Q image thumb

Number 12

357

ID number 4

Q image thumb

Tarsometatarsal joints

358

ID number 14

Q image thumb

Tarsocrural joint

359

Which is the distal intertarsal joint?

Q image thumb

Number 9

360

Which is the medial malleolus of the tibia?

Q image thumb

Number 13

361

ID number 1

Q image thumb

Tarsocrural joint

362

ID numbers 5-10

Q image thumb

5. Superimposed tarsal bones 1 and 2

6. Metatarsal bone 2

7. Metatarsal bone 3

8. Proximal sesamoid bones of digit 3

9. Metatarsophalangeal joint of digit 2

10. Proximal phalanx of digit 2

363

ID number 12-17

Q image thumb

12. Digital pad of digit 3

13. Distal phalanx of digit 3

14. Unguicular process of distal phalanx of digit 4

15. Middle phalanx of digit 4

16. Metatarsal bone 4

17. Metatarsal bone 5

364

ID number 11

Q image thumb

Metatarsal pad

365

ID number 2

Q image thumb

Talus

366

Which number represents the fourth tarsal bone?

Q image thumb

Number 19

367

ID nnumber 4

Q image thumb

Central tarsal bone

368

Which number is the calcaneus?

Q image thumb

Number 21

369

ID number 18

Q image thumb

Tarsometatarsal joints

370

ID numbers 5-9

Q image thumb

5. Tarsal bone 4

6. Base of metatarsal bone 5

7. Body of metatarsal bone 5

8. Proximal sesamoid bones of digit 5

9. Proximal phalanx of digit 5

371

ID numbers 1-5

Q image thumb

1. Superficial digital flexor tendon

2. Tuber calcanei

3. Calcaneus

4. Proximal intertarsal (calcenoquartal) joint

5. Tarsal bone 4

372

Which number is the metatarsal pad?

Q image thumb

Number 10

373

ID numbers 12-18

Q image thumb

12. Distal interphalangeal joint of digit 4

13. Flexor tubercle of distal phalanx of digit 4

14. Middle phalanx of digit 4

15. Unguicular process of distal phalanx of digit 3

16. Unguicular crest of distal phalanx of digit 3

17. Proximal interphalangeal joint of digit 4

18. Metatarsophalangeal joint of digit 4

374

ID the trochlea of the talus

Q image thumb

Number 22

375

ID number 23

Q image thumb

Tarsocrural joint

376

ID numbers 1-4 of the equine elbow joint

Q image thumb

1. Medial epicondyle of the humerus

2. Medial coronoid process of ulna

3. Head of the radius

4. Radial tuberosity

377

ID numbers 5-10 of the equine elbow joint

Q image thumb

5. Proximal interosseous space

6. Trochlea of the humeral condyle

7. Capitulum of the humeral condyle

8. Eminence for lateral collateral ligament

9. Lateral coronoid process of the ulna

10. Lateral epicondyle of the humerus

378

ID numbers 11 and 12 of the equine elbow joint

Q image thumb

11. Tuber olecrani

12. Olecranon fossa of the humerus

379

ID numbers 1-4 of this equine left carpus

Q image thumb

1. Medial styloid process of the radius

2. Lateral styloid process of the ulna

3. Projection at the proximomedial aspect of the medial styloid process of the radius

4. Vascular channels

380

ID numbers 7-12 of the left equine carpus

Q image thumb

7. Radial carpal bone

8. Intermediate carpal bone

9. Ulnar carpal bone

10. Accessory carpal bone

11. Second carpal bone

12. Third carpal bone

381

ID numbers 13-17 of the left equine carpus

Q image thumb

13. Fourth carpal bone

14. Medial border of palmar process of carpal bone 3

15. Metacarpal bone 2

16. Metacarpal bone 4

17. Metacarpal bone 3

382

Which number represents the junction of carpal articular surface with the cranial surface of the radius?

Q image thumb

Number 6

383

ID numbers 19-21

Q image thumb

19. Antebrachiocarpal joint

20. Carpometacarpal joints

21. Middle carpal joints

384

Which number represents the caudolateral border of the medial styloid process of the radius?

Q image thumb

Number 5

385

Which number represents the shadow cast by dorsal aspects and palmar aspects of the carpometacarpal joints?

Q image thumb

22. Shadow cast by dorsal aspects of carpometacarpal joints

23. Shadow cast by palmar aspects of carpometacarpal joints

386

ID numbers 1-3

Q image thumb

1. Antebrachiocarpal joint

2. Middle carpal joint

3. Carpometacarpal joint

387

ID numbers 8-10

Q image thumb

8. Lateral styloid process

9. Transverse crest of the radius

10. Accessory carpal bone

388

ID the medial styloid process

Q image thumb

Number 6

389

ID numbers 11-16

Q image thumb

11. Dorsoproximal border of radial carpal bone

12. Dorsoproximal border of intermediate carpal bone

13. Dorsoproximal border of ulnar carpal bone

14. Dorsodistal border of radial carpal bone

15. Dorsodistal border of intermediate carpal bone

16. Dorsodistal border of ulnar carpal bone

390

ID numbers 17-19

Q image thumb

17. Palmar border of radial carpal bone

18. Palmar border of intermediate carpal bone

19. Palmar border of ulnar carpal bone

391

Number ___ represents the metacarpal bone 2 and number ___ represents metacarpal bone 4

Q image thumb

26. Metacarpal bone 2

27. Metacarpal bone 4

392

ID numbers 20-22

Q image thumb

20. Dorsal border of third carpal bone

21. Dorsal border of fourth carpal bone

22. Dorsal border of second carpal bone

393

Which number is metacarpal bone 3?

Q image thumb

Number 23

394

Which number represents the fourth carpometacarpal joint?

Q image thumb

Number 28

395

ID numbers 1-3 of this left equine metacarpophalangeal joint

Q image thumb

1. Distal end (head) of small metacarpal bone

2. Dorsal part of sagittal ridge of metacarpal bone 3

3. Palmar part of sagittal ridge of metacarpal bone 3

396

ID numbers 4-6 of the left equine metacarpophalangeal joint

Q image thumb

4. Metacarpophalangeal joint

5. Proximal sesamoid bones

6. Ergot

397

ID numbers 7 and 8

Q image thumb

7. Straight sesamoid ligament

8. Proximal interphalangeal joint

398

ID the interosseus

Q image thumb

Number 2

399

ID the superficial digital flexor tendon

Q image thumb

Number 1 and 8

400

ID the deep digital flexor tendon

Q image thumb

Number 3

401

ID the palmar annular ligament of the metacarpophalangeal joint

Q image thumb

Number 7

402

ID number 9

Q image thumb

Ergot

403

ID the Ergot

Q image thumb

Number 5

404

ID the dorsoproximal aspect of the proximal phalanx

Q image thumb

Number 2

405

ID number 6

Q image thumb

Deep digital flexor tendon

406

ID the sagittal ridge on the head of metacarpal bone 3

Q image thumb

Number 1

407

ID number 4

Q image thumb

Proximal sesamoid bones

408

Which number represents the distal end of the small metacarpal bone?

Q image thumb

Number 3

409

What is the view of this left equine foredigit?

Q image thumb

Lateromedial

410

ID numbers 1-3

Q image thumb

1. Proximal interphalangeal joint

2. Extensor process of distal phalanx

3. Distal interphalangeal joint

411

Which number represents the proximal extent of hte tubular horn forming the stratum medium of the hoof wall?

Q image thumb

Number 5

412

Which number represents the junction of the stratum medium and laminar horn of the stratum internum?

Q image thumb

Number 6

413

Which number is part of the distal interphalangeal joint that extends between the distal phalanx and the distal sesamoid (navicular) bone?

Q image thumb

Number 4

414

Which number represents the vascular channels extending from sole canal to the sole border of the distal phalanx?

Q image thumb

Number 10

415

ID the planum cuneatum (sole surface) of the distal phalanx

Q image thumb

Number 9

416

ID the superimposed medial and lateral palmar processes of the distal phalanx

Q image thumb

Number 13

417

Number ___ is the flexor surface of the navicular bone and number ___ is the flexor surface of the distal phalanx

Q image thumb

11. Flexor surface of the distal phalanx

12. Flexor surface of the navicular bone

418

Which is the transverse part of the sole canal of the distal phalanx that accommodates the terminal arch of the digital vessels?

Q image thumb

Number 7

419

What is the view of this radiograph of the left equine foredigit?

Q image thumb

Dorsopalmar

420

ID number 1

Q image thumb

Proximal interphalangeal joint

421

ID numbers 2-4

Q image thumb

2. Lateral distal collateral tubercle of the proximal phalanx

3. Medial proximal collateral tubercle of the middle phalanx

4. Extensor process of the distal phalanx

422

ID the distal interphalangeal joint

Q image thumb

Number 6

423

Which is the foramen in the lateral palmar process of the distal phalanx that accommodates dorsal branches of digital vessels?

Q image thumb

Number 9

424

Which is the sole border of the distal phalanx that is typically irregular because of notches for vascular channels?

Q image thumb

Number 11

425

ID the lateral palmar process of the distal phalanx?

Q image thumb

Number 8

426

Which is the medial sole foramen of the distal phalanx which receives digital vessels as they enter the sole canal?

Q image thumb

Number 10

427

ID number 7

Q image thumb

Lateral extremity of the navicular bone

428

ID numbers 12 and 13

Q image thumb

12. Medial collateral groove of the frog

13. Central groove of the frog

429

What is number 14?

Q image thumb

Notch in the sole border associated with vascular channels from the sole canal of the distal phalanx

430

ID numbers 3-7

Q image thumb

3. Lateral condyle of the femur

4. Medial condyle of the femur

5. Lateral tubercle of the intercondylar eminence

6. Lateral condyle of the tibia

7. Medial condyle of the tibia

431

ID the supercondylar fossa of hte femur for SDF

Q image thumb

Number 1

432

Which is the medial tubercle of the intercondylar eminence?

Q image thumb

Number 2

433

ID numbers 13-15

Q image thumb

13. Medial ridge of the femoral trochlea

14. Extensor fossa of the femur

15. Lateral ridge of the femoral trochlea

434

ID number 8

Q image thumb

Fibula

435

Match the following with numbers 9-12:

Groove for intermediate patellar ligament

Lateral part of the tibial tuberosity

Extensor groove of the tibia

Cranial intercondylar area of the tibia

Q image thumb

9. Extensor groove of the tibia

10. Groove for intermediate patellar ligament

11. Lateral part of the tibial tuberosity

12. Cranial intercondylar area of the tibia

436

Which is the gliding part and which is the resting part of the articular surface of the patella?

Q image thumb

17. Articular surface of the patella, gliding part

18. Articular surface of the patella, resting part

437

What number is the base of the patella and which number is the apex of the patella?

Q image thumb

16. Apex of patella

19. Base of patella

438

ID the patella

Q image thumb

Number 17

439

Number ____ is the head of the fibula and number____ is the body of the fibula

Q image thumb

8. Body of the fibula

9. Head of the fibula

440

ID numbers 1-4

Q image thumb

1. Intercondylar fossa of the femur

2. Medial tubercle of the intercondylar eminence

3. Medial epicondyle of the femur

4. Medial condyle of the femur

441

Which is the cranial margin of the tibia?

Q image thumb

Number 7

442

ID number 5

Q image thumb

Medial condyle of the tibia

443

ID numbers 10-12

Q image thumb

10. Lateral part of the tibial tuberosity

11. Lateral condyle of the tibia

12. Lateral meniscus and femorotibial joint

444

Which is the medial condyle of the tibia?

Q image thumb

Number 6

445

ID numbers 14-16

Q image thumb

14. Lateral tubercle of the intercondylar eminence

15. Lateral epicondyle of the femur

16. Lateral ridge of the femoral trochlea

446

ID the depression for origin of the popliteus muscle

Q image thumb

Number 13

447

What is the view of this radiograph of the left equine tarsus?

Q image thumb

Dorsoplantar

448

ID numbers 6-8 in regards to the malleolus

Q image thumb

6. Medial malleolus

7. Caudal part of the lateral malleolus

8. Cranial part of the lateral malleolus

449

ID numbers 12-17

Q image thumb

12. Lateral ridge of the trochlea tali

13. Proximal tubercle of the talus

14. Distal tubercle of the talus

15. Medial ridge of the trochlea tali

16. Groove between lateral and medial ridges of trochlea tali

17. Medial edge of the sustentaculum tali

450

Number 10 is the ____ and number 11 is the ____.

Q image thumb

10. Talus

11. Calcaneus

451

ID numbers 1-3 in regards to the tibial cochlea

Q image thumb

1. Medial groove of the tibial cochlea

2. Lateral groove of the tibial cochlea

3. Oblique ridge separating medial and lateral groove of the tibial cochlea

452

Which is the pointed caudal end of the oblique ridge and which is the rounded cranial end of the oblique ridge?

Q image thumb

4. Pointed caudal end of the oblique ridge

5. Rounded cranial end of the oblique ridge

453

ID number 19

Q image thumb

Tuber calcanei

454

Which is the proximal intertarsal (talocalcenocentral) joint and which is the proximal intertarsal (calcaneoquartal) joint?

Q image thumb

18. Proximal intertarsal (talocalcaneocentral) joint

20. Proximal intertarsal (calcaneoquartal) joint

455

Which is the articulation between the first and second tarsal bones and metatarsal bone 2?

Q image thumb

Number 26

456

Which is the distal intertarsal (centrodistal) joint?

Q image thumb

Number 24

457

Which is the medial aspect and which is the lateral aspect of the central tarsal bone?

Q image thumb

22. Medial aspect of the central tarsal bone

23. Lateral aspect of the central tarsal bone

458

Number 21 is the ___ aspect of the central tarsal bone

Q image thumb

Proximoplantar

459

ID number 30

Q image thumb

Fourth tarsal bone

460

ID the tarsometatarsal joints

Q image thumb

Number 31

461

ID numebrs 27 and 28

Q image thumb

27. Medial aspect of the third tarsal bone

28. Lateral aspect of the third tarsal bone

462

ID numbers 32 and 33

Q image thumb

32. Base of metatarsal bone 2

33. Base of metatarsal bone 4

463

What is the view of this left equine tarsus radiograph?

Q image thumb

Lateromedial

464

ID numbers 1 and 2

Q image thumb

1. Lateral malleolus

2. Medial malleolus

465

ID the larger notch associated with the lateral ridge of the trochlea tali?

Q image thumb

Number 9

466

ID numbers 5-8

Q image thumb

5. Sustentaculum tali

6. Tuber calcanei

7. Lateral ridge of the trochlea tali

8. Medial ridge of the trochlea tali

467

ID the chestnut

Q image thumb

Number 22

468

ID numbers 17-19

Q image thumb

17. Base of metatarsal bone 2

18. Base of metatarsal bone 3

19. Base of metatarsal bone 4

469

ID the intermediate part of the tibial cochlea

Q image thumb

Number 10

470

ID number 12

Q image thumb

Proximal intertarsal joint

471

ID the distal intertarsal joint

Q image thumb

Number 16

472

ID the groove of the trochlea tali

Q image thumb

Number 11

473

Which is the groove on metatarsal bone 3 for dorsal metatarsal artery 3?

Q image thumb

Number 21

474

ID number 14

Q image thumb

Plantar aspect of the proximal intertarsal joint

475

Which is the articular facets between the talus and the calcaneus?

Q image thumb

Number 13

476

Which is the articulation between the central tarsal bone and the fused first and scond tarsal bones?

Q image thumb

Number 15

477

ID number 11

Q image thumb

Crena marginis solaris

478

ID numbers 1-3

Q image thumb

1. Proximal interphalangeal joint

2. Medial palmar process of distal phalanx

3. Proximal border of the navicular bone

479

ID number 12

Q image thumb

Apex of the frog

480

ID number 8

Q image thumb

Distal interphalangeal joint

481

Match the following with numbers 5-7:

Lateral extremity of the navicular bone

Air within the central groove of the frog

Sole canal of the distal phalanx

Q image thumb

5. Air within the central groove of the frog

6. Lateral extremity of the navicular bone

7. Sole canal of the distal phalanx

482

Which number corresponds to the vascualr channel from sole canal to the sole border of the distal phalanx?

Q image thumb

Number 13

483

Which number is the sole border of the distal phalanx?

Q image thumb

Number 10

484

ID the articulation of the distal phalanx with the navicular bone that is part of the interphalangeal joint.

Q image thumb

Number 9

485

What is the origin and insertion point of the deltoideus muscle?

Origin: Scapular Spine and Acromium

Insertion: Deltoid Tuberosity

486

What is the origin and insertion point of the Triceps brachii muscle?

Origin: Proximal Humerus

Insertion: Olecranon Tuber

487

What is the origin and insertion point of the Biceps brachii?

Origin: Supraglenoid tubercle

Insertion: Ulnar and Radial Tuberosities

488

What is the origin of most of the extensor muscles of the antebrachium?

Origin: Lateral epicondyle

489

What is the origin of most of the flexor muscles of the antebrachium?

Medial epicondyle

490

What is the origin of the hamstring muscles?

Ischiatic Tuberosity

491

What is the origin and insertion point of the superficial gluteal muscle?

Origin: Lateral border of the sacrum and first caudal vertebra

Insertion: Third trochanter

492

What is the origin and insertion of the middle gluteal muscle?

Origin: Crest and Gluteal surface of the ilium

Insertion: Greater trochanter

493

What is the origin and insertion point of the deep gluteal muscle?

Origin: Body of the ilium and ischiatic spine

Insertion: Greater trochanter

494

What is the origin and insertion point of the quads?

Origin: Ilium and proximal femur

Insertion: Tibial tuberosity

495

What is the origin and insertion point of the iliopsoas muscle?

Origin: Spine and ilium

Insertion: Lesser trochanter
