Heme Images Flashcards Preview

Heme > Heme Images > Flashcards

Flashcards in Heme Images Deck (63):
1

What are these?

Q image thumb

normal RBC

2

Q image thumb

eosinophil

3

Q image thumb

Basophil

4

Q image thumb

Neutrophil

5

Q image thumb

Monocyte

6

Q image thumb

Lymphocyte

7

Q image thumb

Platelets

(small, aneucleate)

8

Q image thumb

Band

9

Q image thumb

Metamyelocyte

10

What is occuring in the cytoplasm of this neutrophil?

Q image thumb

toxic granulation

11

Q image thumb

reactive lymphocyte

(larger nuclei and lots of cytoplasm)

12

What abnormality is demonstrated by these RBC?

Q image thumb

hypochromia

13

What structural abnormalities are demonstrated in these RBC?

Q image thumb

Anisocytosis,
poikilocytosis

14

What abnormality is demonstrated by this cell?

Q image thumb

Polychromasia

(residual mRNA is present in RBC)

15

Q image thumb

Sickle cell

16

Q image thumb

bite cells

17

Q image thumb

schistocyte

18

Q image thumb

Heinz bodies

19

Q image thumb

bite cells

20

Q image thumb

Howell Jolly bodies

21

Q image thumb

Hgb C crystals

22

What's the condition?

Q image thumb

SCD Hgb SC

23

Q image thumb

sickle cell anemia

24

What condition?

Q image thumb

microcytic hemolytic anemia

(schistocytes)

25

What condition?

Q image thumb

Iron deficiency anemia

(microcytic, hypochromic)

26

What condition?

Q image thumb

Sickle Cell SC

(note central cell and target cells)

27

What condition?

Q image thumb

Megaloblastic/Macrocytic anemia

(large RBC due to DNA synthesis errors; hypersegmented neutrophil)



28

Q image thumb

Howell Jolly Body

29

What's the upper left cell?

Q image thumb

nucleatued RBC

30

What condition?

Q image thumb

Spherocytosis

31

Q image thumb

basophilic stippling

32

(Bone marrow)

Q image thumb

ringed sideroblasts (in sideroblastic anemia)

33

Q image thumb

spherocyte

34

What deficiency?

Q image thumb

pyruvate kinase

35

Q image thumb

bite cell

36

Q image thumb

AML



(some myelocyte maturation with auer bodies)

37

Q image thumb

acute premyelocytic leukemia



(more mature, pink blasts, stacks of auer rods)

38

Q image thumb

Acute monocytic leukemia

39

Q image thumb

Chronic Myelogenous Leukemia

40

Q image thumb

Acute myeloid leukemia

41

Q image thumb

Myelofibrosis

(tear drop cells)

42

What condition? (this is bone marrow)

Q image thumb

myelofibrosis

43

What condition?

Q image thumb

chronic myelogenous leukemia

44

What condition?

Q image thumb

essential thrmbocythemia (increased number/size of platelets)

45

What condition?

Q image thumb

infectious mono

46

What condition?

Q image thumb

Hodgkin lymphoma

(note RS cell)

47

What condition?

Q image thumb

Essential thrombocythemia

48

What's the condition?

(note: hypersegmented neutrophil and abn RBC's)

pernicious anemia



"This hypersegmented neutrophil is present along with macro-ovalocytes in a case of pernicious anemia. Compare the size of the RBC's to the lymphocyte at the lower left center." --WebPath

49

What are these two abnormal cells?

RBC with Howell-Jolly Bodies

Nucleated RBC

50

What protein is absent in these RBCs?

spectrin (hereditary sphereocytosis)

51

What condition (and subtype) is this consistent with?

CML

Philadelphia chromosome (+)

52

What condition? (this is sectioned vertebral bone)

multiple myeloma

53

Reed-Sternberg cells (Hodgkin's)

54

What's the condition?

(sorry if this is fuzzy)

AML

55

What's the condition?

myelofibrosis

(also thalassemia)

56

What's the condition?

(note: hypersegmented neutrophil and abn RBC's)

Q image thumb

pernicious anemia



"This hypersegmented neutrophil is present along with macro-ovalocytes in a case of pernicious anemia. Compare the size of the RBC's to the lymphocyte at the lower left center." --WebPath

57

What are these two abnormal cells?

Q image thumb

RBC with Howell-Jolly Bodies

Nucleated RBC

58

What protein is absent in these RBCs?

Q image thumb

spectrin (hereditary sphereocytosis)

59

What condition (and subtype) is this consistent with?

Q image thumb

CML

Philadelphia chromosome (+)

60

What condition? (this is sectioned vertebral bone)

Q image thumb

multiple myeloma

61

Q image thumb

Reed-Sternberg cells (Hodgkin's)

62

What's the condition?

(sorry if this is fuzzy)

Q image thumb

AML

63

What's the condition?

Q image thumb

myelofibrosis

(also thalassemia)
